Description
Blue Whale 1 is a two-stage orbital launch vehicle capable of placing a 150 kg payload into a 500 km Sun-Synchronous Orbit with the fully reusable first stage.
By using liquid oxygen and methane as propellants for both stages, BW1 emits far fewer carbon pollutants into the atmosphere. It also enables higher engine performance and better maintainability. For lightweight construction, Blue Whale is mainly constructed from high-strength carbon composites, improving payload mass fraction for such a small and lightweight launch vehicle.
The flight test program will begin in late 2024, followed by commercial flights in 2025. With a total launch price of less than $3M, it is the most affordable launch vehicle in the world.
Thesaurus
rdfs:label : Blue Whale 1
Browsing
produced by this Company Perigee_Aerospace
produced in this Country Korea
belongs to this Weapon System space-based_system
belongs to this Weapon Categories Future
Specifications
Payload_to_500_km_sso | 170 kg |
Payload_to_500_km_Leo | 150 kg |
Launch_mass | 19,800 kg |
Dry_Mass | 1,510 kg |
Total_Length | 21.0 m |
Nominal_Diameter | 1,600 mm |
Thrust_at_liftoff | 260 kN |
LAUNCH_SITE | Blue Whale 1 operates in two launch sites: Esrange Space Center and Jeju Launch Center. Both sites are ideal for high cadence launches at low operational costs. |
